NSQ/ZJQ submersible slurry pump has excellent material selection, advanced structure, wide overflow channel and strong sewage discharge capability. It is suitable for conveying liquids containing solid particles such as sand, coal slag etc. It is mainly used for transportation of mud
liquids in enterprises such as metallurgy, mining, and thermal power plants.In addition to the main impeller, the water pump adds a set of agitating impellers at the bottom, which can spray the settled sludge into turbulent flow. The pump can achieve high-concentration transportation
without auxiliary devices.
Features:
- The whole machine adopts the dry pump type pump structure. Themotor protected by a mechanical seal, which can effectively preventhigh-pressure water and impurities from entering the motor cavity.，
- In addition to the main impeller, there is also a stirring impeller, whichcan stir the sludge deposited on the bottom of the water into a turbulentflow and extract it.
- The main flow parts such as impeller ,agitating impeller and pump body are madeof highly wear-resistant materials, which are resistant to wear, corrosion,non-clogging, and have a strong sewage discharge capability, and can effectively pass larger solid particles.
- It is not limited by the suction stroke, the slag suction efficiency ishigh, and the dredging is more thorough.
- No need to equip auxiliary vacuum pump, so the investment is cheaper.
