- The motor and pump are integrated into the water andoperate safely and reliably.
- There are no special requirements forwell pipes and water pipes (ie: steel pipe wells can be used; under pressure permit,steel pipes,hoses, plastic pipes,etc.can be used as water pipes).
- it is easy to install, use and maintain. It occupies a smallarea and does not require the construction of a pump room,
- Simple structure and save raw materials. However, whetherthe submersible electric pumps are used in appropriate conditions is directly related to their service life.
Application
- For water supply from wells or reservoirs.
- For domestic use,for civil and industrial applications.
- For garden use and irrigation.
Operating Conditions
- Maximum fluid temperature up to+40℃
- Maximum sand content:0.25%
- Maximumimmersion:70m
- Minimum well diameter:3′
Usage Precautions:
- SDM series deep well pump equip with oil filled motor, do not addany water into motor.
- No warranty if install in the water with too many sediment.
- Please confirm with us in advance about the length cable size
- Non-return valve must be installed
Motor and Pump
- Three-phase:380v-415V/50Hz
- Single-phase:220V-240V/50Hz
- Pumps are designed by casing stressed
Options on Request
- Equip digital auto-control box
- Special mechanical seal
- Other voltages or frequency 60 Hz
