CDLF is a multi-functional product that can transport various media from tap water to industrial liquids, suitable for different temperature, flow and pressure ranges, CDLF is suitable for mild corrosion Sexual liquid.
Application
- Water supply: water plant filtration and delivery, waterplant district water delivery, main pressurization, high-rise building pressurization.
- Industrial pressurization:process water system.cleaningsystem, high pressure washing system, fire fighting system Industrial liquid transportation: cooling and air conditioning system, boiler feed water and condensation system,machine
- tool supporting,acid and alkali.
- Water treatment:ultrafiltration system,reverse osmosis system, distillation system, separator, swimming pool.
- irrigation:farmland irrigation, sprinklerirrigation, drip irrigation
Operating conditions
- Thin,clean,non-flammable and explosive liquidwithout solid particles or fibers.
- Liquid temperature:normal temperature type-15℃
to +70℃
Hot water type +70℃ to +120℃
- Ambient temperature: up to +40℃
- Altitude:1000m
If applied to plateau area, choose plateau motor
Various customizations:
- 220V single motor can be customized
- 60HZ motor can be customized
- Explosion-proof motor can be customized
- pump body and impeller can be customized316 316L material.
- The four O-rings of mechanical seal can choosefluororubber,ethylene propylene rubber and tetrafluoroethylene.
- The outletis generally a which can be customized with thread threads,ferrules,clamps, oval flanges, etc.
Motor
- The motoris a fully enclosed,air-cooled secondary standard motor.
- Protection grade:lP55
- Insulation class: F
